Technical features
- Independent programming of the sidewall gluing path between the hollow and external sides
- Programming of the sidewall lasting path with the option of adjusting height, rotation speed, pressure, and feed speed
- Programming of the sidewall nailing path independently between the hollow and external sides, with the option of selecting the nail type and space between the nails
- Tracer unit with thermoplastic glue and programmed temperature control
- Possibility of gluing the heelseat with tracerss (all-glue lasting)
- Side nail loaders with the option of selecting two nail sizes
- Side shoe holding units with programmed inclination adjustment and manual adjustment of the height and position of the individual holding fingers
- Nailing of the shoe with inclined nails and selection of the number of nails: 18, 20 (standard) and 22 (optional)
- Programming of the position of the heelseat nailer with automatic switching for right/left shoe.
- Toe support programmable in height and length
- Upper pulling unit with independent and programmable pincers.
- Programmable last support column (entry/exit) for optimal control of the lasting position
- Pneumatic sensor with electronic adjustment of the last height during loading
- Control console with 15″ color touchscreen and the option of positioning to the right or left of the operator
- Integrated self-diagnostic functions
- Compliant with Industry 4.0 requirements
